Folding Glazed Panels

Supertherm 80

A sophisticated design of thermal breaks and insulation allow this system to reach its high level of thermal efficiency.

Attractive design and superior engineering ensure maximum longevity. A wide choice of options and combinations allow for individual design solutions.

Keep the outside, outside. ST80 folding doors are designed to keep the weather out when closed and allow you to get the most from summer days when open.

Stringent testing at renowned European test centres prove the abilities of this technologically advanced product.

With endless configurations possible and flush thresholds achievable, this versatile system offers unlimited design solutions coupled with the reassurance of superior quality engineering

Construction: Thermally broken aluminium with insulated cavity
Insulation: U Value of between 0.9 - 1.4
Glazing: Toughened or laminated, double or triple glazed Low-E units, all glass types up to 62mm thick possible. In-glazed blinds available on request.
Frame Finish: aAwide range of colours with the option of different colours inside and out
Ironmongery: Standard, colour matched or satin stainless steel
Panel width: max 1200mm
Panel height: max 3000mm
Panel thickness: 80mm
Security: Three point locking mechanism with high security cylinder locks

Thermo 60

This popular system of robust yet slim thermally broken aluminium frames set the industry standard for quality and thermal efficiency in a folding door.

Used to manufacture a variety of matching glazing systems, Thermo60 can be tailored to suit your needs.

Thermo60 folding doors can open inwards or outwards with panels stacking to the left, right or bi-parting.

Floating stacks are also available as are static or sliding corner posts.

Floor tracks have the option of a unique retractable weather bar providing a flush track solution without compromising the weather rating.

This adaptable system can be either top hung or floor supported.

Construction: Thermally broken aluminium with insulated cavity
Insulation: U Value of between 1.2 - 1.65
Glazing: Toughened or laminated, double or triple glazed Low-E units, all glass types up to 42mm thick possible. In-glazed blinds available on request.
Frame Finish: A wide range of colours with the option of different colours inside and out
Ironmongery: Standard, colour matched or satin stainless steel
Panel width: max 1100mm
Panel height: max 2700mm
Panel thickness: 60mm
Security: Three point locking mechanism with high security cylinder locks
